Conveyor Impact Bed Bar For Loading Zone Impact Resistant

Conveyor Impact Bed Bar For Loading Zone Impact Resistant
Conveyor Impact Bed Bar For Loading Zone Impact Resistant Conveyor Impact Bed Bar For Loading Zone Impact Resistant Conveyor Impact Bed Bar For Loading Zone Impact Resistant Conveyor Impact Bed Bar For Loading Zone Impact Resistant Conveyor Impact Bed Bar For Loading Zone Impact Resistant

Large Image :  Conveyor Impact Bed Bar For Loading Zone Impact Resistant

Product Details:
Place of Origin: China
Brand Name: DEBON
Certification: SGS, ISO, GB
Model Number: DB-HCCB
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: USD 15-50 per piece
Packaging Details: carton + pallet
Delivery Time: 5-10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20000 pcs per month

Conveyor Impact Bed Bar For Loading Zone Impact Resistant

Description
Material: UHMWPE, Rubber, Steel, Aluminium Product Name: Conveyor Belt Load Zone Conveyor Impact Bar Impact Resistant Impact Bed Impact Bar
Keyword: Impact Bar Thick: 55mm, 75mm
Wide: 100mm Length: 1220mm, 1400mm, 1500mm, 1800mm, 2000mm
Hardness: 65 Shore A Advantage: Factory Price, High Quality, Warranty, Experience
Benefits: Reduces Impact Force, Support Conveyor Belt Customize: We Could Make As Per Request
High Light:

Impact Bed Bar For Loading Zone

,

Impact Resistant Conveyor Impact Bed

,

Conveyor Loading Zone Impact Bed Bar





Conveyor Belt Load Zone Conveyor Impact Bar Impact Resistant Impact Bed Impact Bar





Impact bar:
Used in the conveyor loading points or transfer points to replace traditional conveyor rollers.

It's designed to absorb impact loading and help eliminate spillage and scattering of the products. This results in less wear and tear on your conveyor system, dramatically improves the efficiency and reduces the maintenance cost.





About conveyor impact bar:

1. UHMWPE cap + rubber cusion + steel T-slot or Aluminium T-slot

2. high wear resistant, impact resistant, belt supporting, protect conveyor belt,

3. easy installing and replacement.





Advantages & Features of Conveyor Impact Bars:

  • high impact and bending strength make sure longer service life
  • Aluminum slot for quick installation with 3~5 square or T bolts
  • Premium impact resistant rubber provides excellent cushioning and impact absorption.
  • 12mm/15mm/25mm UHMW top ensure lower friction
  • The 3 parts are permanently bonded through our special molding and vulcanization process.



Design of our Impact Bars:
-UHMWPE Cap
-Cushioning rubber
-Aluminum T-slot




Specification:

Item Size (mm) Length (mm)
Impact Bar Standard 1 100*55 1220/1400/1500/2010,etc
Impact Bar Standard 2 100*75 1220/1400/1500/2010,etc
Impact Bar Heavy Duty 280*100 1080




Standard Screw:
M12
M16
1 Set of screws includes bolts, gromment and nut.
