Square 100x100 Ceramic Wear Plate Lining For Chute Hopper

Certification
China Jiaozuo Debon Technology Co., Ltd. certification
I'm Online Chat Now

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper
Square 100x100 Ceramic Wear Plate Lining For Chute Hopper
Square 100x100 Ceramic Wear Plate Lining For Chute Hopper Square 100x100 Ceramic Wear Plate Lining For Chute Hopper Square 100x100 Ceramic Wear Plate Lining For Chute Hopper Square 100x100 Ceramic Wear Plate Lining For Chute Hopper

Large Image :  Square 100x100 Ceramic Wear Plate Lining For Chute Hopper

Product Details:
Place of Origin: CHINA
Brand Name: Debon
Certification: SGS, ISO9001
Model Number: DB-TCM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Crate or Pallet
Delivery Time: 7-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 pcs per month

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper

Description
Name: Alumina Ceramic Liner Material: High Alumina Ceramic, Zta Cearmic, HPA Ceramic
Fastening: Bolt On, Magnetic, CN Bonding Layer, Countersinks Etc. Ceramic Shape: Custom Shapes And Sizes Available
Type: Ceramic Tiles, Ceramic Plates. Ceramic Rubber Composite Mat/plate/sheets/liner Steel Backing Plate: Mild Steel Or Stainless Steel Or Megnet Backed
Advantage: Factory Price,high Quality,warranty Processing Service: Bending, Welding, Cutting, Punching, Moulding
Application: Mining Industry; Cement Industry; Power Generation Industry; Steel Industry; Chemical Industry HS Code: 6909120000
High Light:

Square 100x100 Ceramic Wear Plate

,

100x100 Square Ceramic Wear Plate

,

100x100 Square Ceramic Wear Plates

Ceramic Wear Plate 100x100x25 Wear Resistant Wear Liner For Chute Hopper



Alumina Ceramic Liner Description:



Alumina ceramic liner is a type of wear-resistant lining material used to protect industrial equipment from abrasion, impact, and corrosion. It is made of high-density alumina ceramic tiles or panels that are bonded to a substrate such as steel or rubber.



The alumina ceramic tiles are arranged in a specific pattern to provide maximum protection against wear and impact. They are known for their exceptional hardness and wear resistance, which make them ideal for use in harsh industrial environments.

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper 0

Alumina Ceramic Liner Install Method:



Bolt On Cermaic Rubber Liners are produced with steel backing plate and studs
Bolt On Ceramic wear liner with steel plate and countersinks, such liners can be bolted on to your chute
Bonding on CN layer backed ceramic wear liners can be bonded to your facility by adhesive
Magnetic Ceramic liners Easy to install

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper 1



Alumina Ceramic Liner Specification:



Item Description Unit Result
Alumina Ceramic Wear Tiles
1 Alumina (Al2O3) % 92 , 95
2 Density g/cm3 3.64
3 Water absorption % ≤0.01
4 Hardness Mohs 9
Rubber
1 Material   NR or SBR
2 Gravity g/cm3 1.15
3 Tensile Strength MPa 15 min.
4 Hardness Shore A 55+/-5
5 Elongation % 400 min
6 Abrasion Loss mm3 ≤90
7 Aging Coefficient (70°C x 48h) % 8.7



Square 100x100 Ceramic Wear Plate Lining For Chute Hopper 2

Alumina Ceramic Liner Features:



  • High wear and abrasion resistance
  • Long wear life, low maintenance and downtime
  • Significant noise reduction
  • Available in awide variety of shapes and sizes
  • Corrosion resistant



Square 100x100 Ceramic Wear Plate Lining For Chute Hopper 3

Alumina Ceramic Liner Application:



  1. Mining industry

  2. Cement industry

  3. Power generation industry

  4. Steel industry

  5. Chemical industry

  6. Military industry

Square 100x100 Ceramic Wear Plate Lining For Chute Hopper 4

Why choose us:



1. Alumina ceramic liner manufacturer.

2. Reliable factory with extensive experience.

3. High quality and consistency

4. ISO9001, ISO45001, ISO14001 certified factory.



We are a factory dedicated to producing ceramic wear liner and have been improving the properties of ceramics. We use high quality rubber to offer better impact resistance and high quality rubber can also help holding the ceramic tiles, no ceramic tiles falling.
